AT A GLANCE
路Lens Mount Micro Four Thirds
路Camera Format Micro Four Thirds (2x Crop Factor)
路Pixels Actual: 21.8 Megapixel
路Effective: 20.3 Megapixel
路Maximum Resolution 5184 x 3888
路Aspect Ratio 4:3
路Sensor Type MOS
路Sensor Size 17.4 x 13 mm
路Image File Format JPEG, Raw
路Bit Depth 12-Bit
路Image Stabilization Sensor-Shift, 5-Axis
路Exposure Control
路ISO Sensitivity Auto, 200 to 25600 (Extended: 100 to 25600)
路Shutter Speed Mechanical Shutter 1/4000 to 60 Second, 0 to 3 Hour in Bulb Mode
路Electronic Front Curtain Shutter 1/320 to 60 Second
路Electronic Shutter 1/16000 to 60 Second
路Metering Method Center-Weighted Average, Multi-Zone, Spot
路Exposure Modes Aperture Priority, Auto, Manual, Program, Shutter Priority
路Exposure Compensation -5 to +5 EV (1/3, 1/2, 1 EV Steps)
路Metering Range -2 to 20 EV
路White Balance Auto, Color Temperature
路Continuous Shooting Mechanical Shutter Up to 8.7 fps at 20.3 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG)
路Mechanical Shutter Up to 5 fps at 20.3 MP for Unlimited Frames (Raw) / Unlimited Frames (JPEG)
路Electronic Shutter Up to 15 fps at 20.3 MP for up to 42 Frames (Raw) / 49 Frames (JPEG)
路Electronic Shutter Up to 6.3 fps at 20.3 MP for up to 945 Frames (Raw) / Unlimited Frames (JPEG)
路Interval Recording Yes
路Self-Timer 2/12-Second Delay
路Video:
路Recording Modes H.264/MOV UHD 4K (3840 x 2160) at 23.976p/25p/29.97p [102 Mb/s] Full HD (1920 x 1080) at 3.976p/25p/29.97p/50p/59.94p/119.88p [18 to 52 Mb/s]
路HD (1280 x 720) at 23.976p/25p/29.97p/50p/59.94p [10 to 26 Mb/s] MOV HD (1280 x 720) at 119.88p
路External Recording Modes UHD 4K (3840 x 2160) up to 29.97p
路Recording Limit Up to 29 Minutes
路Video Encoding NTSC/PAL
路Audio Recording Built-In Microphone (Stereo)
路Audio File Format Linear PCM (Stereo)
路Focus
路Focus Type Auto and Manual Focus
路Focus Mode Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S)
路Autofocus Points Contrast Detection: 121
路Viewfinder and Monitor
路Viewfinder Type Electronic (OLED)
路Viewfinder Resolution 2,360,000 Dot
路Viewfinder Eye Point 19.2 mm
路Viewfinder Coverage 100%
路Viewfinder Magnification Approx. 0.67x
路Diopter Adjustment -4 to +2
路Monitor Size 3"
路Monitor Resolution 1,040,000 Dot
路Monitor Type 180° Tilting Touchscreen LCD
路Flash
路Built-In Flash Yes
路Flash Modes Fill Flash, Off, Red-Eye Reduction, Second-Curtain Sync, Slow Sync, Slow Sync/Red-Eye Reduction
路Guide Number 16.73' / 5.1 m at ISO 100
路Maximum Sync Speed 1/250 Second
路Flash Compensation -3 to +3 EV (1/3, 1/2, 1 EV Steps)
路Dedicated Flash System TTL
路External Flash Connection Hot Shoe
路Interface
路Memory Card Slot Single Slot: SD/SDHC/SDXC (UHS-II)
路Connectivity USB Micro-B (USB 2.0), HDMI D (Micro)
路Wireless Bluetooth
路Wi-Fi
路GPS No
路Environmental
路Operating Temperature 14 to 104°F / -10 to 40°C
路Operating Humidity 30 to 90%
路Storage Temperature -4 to 140°F / -20 to 60°C
路Storage Humidity 10 to 90%
路Physical
路Battery 1 x BLS-50 Rechargeable Lithium-Ion, 7.2 VDC, 1175 mAh (Approx. 360 Shots)
路Dimensions (W x H x D) 4.79 x 3.32 x 1.93" / 121.7 x 84.4 x 49 mm
路Weight 11.82 oz / 335 g (Body Only)
路17.04 oz / 483 g (Body with Battery and Memory)
路Kit Lens
路Focal Length 14 to 42mm (35mm Equivalent Focal Length: 28 to 84mm)
路Maximum Aperture f/3.5 to 5.6
路Minimum Aperture f/22
路Angle of View 75° to 29°
路Maximum Magnification 0.23x
路Minimum Focus Distance 7.87" / 20 cm
路Optical Design 8 Elements in 7 Groups
路Diaphragm Blades 5, Rounded
路Focus Type Autofocus
路Image Stabilization No
路Filter Size 37 mm (Front)
路Dimensions (ø x L) 2.4 x 0.9" / 61 x 22.9 mm
路Weight 3.21 oz / 91 g
